Creating Models

useR2022

Emil Hvitfelt

What is a model?

In tidymodels, there is the idea that a model-oriented data analysis consists of

a preprocessor, and
a model

The preprocessor might be a simple formula or a sophisticated recipe.

It’s important to consider both of these activities as part of the data analysis process.

Post-model activities should also be included there (e.g. calibration, cut-off optimization, etc.)
(We don’t have those implemented yet)

Basic tidymodels components

A relevant example

Let’s say that we have some highly correlated predictors and we want to reduce the correlation by first applying principal component analysis to the data.

AKA principal component regression

A relevant example

Let’s say that we have some highly correlated predictors and we want to reduce the correlation by first applying principal component analysis to the data.

AKA ~~principal component regression~~ feature extraction

A relevant example

Let’s say that we have some highly correlated predictors and we want to reduce the correlation by first applying principal component analysis to the data.

AKA ~~principal component regression~~ feature extraction

What do we consider the estimation part of this process?

Is it this?

Or is it this?

What’s the difference?

It is easy to think that the model fit is the only estimation steps.

There are cases where this could go really wrong:

Poor estimation of performance (buy treating the PCA parts as known)
Selection bias in feature selection
Information/data leakage

These problems are exacerbated as the preprocessors increase in complexity and/or effectiveness.

We’ll come back to this at the end of this section

Data Splitting

Always have a seperate

piece of data that can

contradict

what you believe

Data splitting and spending

How do we “spend” the data to find an optimal model?

We typically split data into training and test data sets:

Training Set: these data are used to estimate model parameters and to pick the values of the complexity parameter(s) for the model.
Test Set: these data can be used to get an independent assessment of model efficacy. They should not be used during model training (like, at all).

Data splitting and spending

The more data we spend, the better estimates we’ll get (provided the data is accurate).

Given a fixed amount of data:

Too much spent in training won’t allow us to get a good assessment of predictive performance. We may find a model that fits the training data very well, but is not generalizable (overfitting)
Too much spent in testing won’t allow us to get a good assessment of model parameters

Statistically, the best course of action would be to use all the data for model building and use statistical methods to get good estimates of error.

From a non-statistical perspective, many consumers of complex models emphasize the need for an untouched set of samples to evaluate performance.

Mechanics of data splitting

There are a few different ways to do the split: simple random sampling, stratified sampling based on the outcome, by date, or methods that focus on the distribution of the predictors.

For stratification:

classification: this would mean sampling within the classes to preserve the distribution of the outcome in the training and test sets
regression: determine the quartiles of the data set and sample within those artificial groups

For time series, we often use the most recent data as the test set.

Cleaning the data

We don’t need all the variables, and some are not encoded in a nice manner

library(tidymodels)
library(elevators)
number_extractor <- function(x) {
  x <- stringr::str_extract(x, "[0-9]+")
  x <- as.integer(x)
  x[x > 100] <- NA
  x
}

elevators_cleaned <- elevators %>%
  mutate(speed_fpm = log(speed_fpm + 0.5),
         floor_from = number_extractor(floor_from),
         floor_to = number_extractor(floor_to),
         travel_distance = number_extractor(travel_distance)) %>%
  select(-device_number, -bin, -tax_block, -tax_lot, -house_number,
         -street_name, -zip_code)

Splitting with elevators data

initial_split() can be used when we use randomness to make the split.

set.seed(1234)
elevators_split <- initial_split(elevators_cleaned)
elevators_split
#> <Analysis/Assess/Total>
#> <26281/8761/35042>

elevators_train <- training(elevators_split)
elevators_test  <- testing(elevators_split)

c(training = nrow(elevators_train), testing = nrow(elevators_test))
#> training  testing
#>    26281     8761

Creating Models in R

Specifying models in R using formulas

To fit a model to the housing data, the model terms must be specified. Historically, there are two main interfaces for doing this.

The formula interface using R formula rules to specify a symbolic representation of the terms:

Variables + interactions

# day_of_week is not in the data set but day_of_week = lubridate::wday(lastper_insp_date, label = TRUE)
model_fn(speed_fpm ~ day_of_week + car_buffer_type + day_of_week:car_buffer_type,
         data = elevators_train)

Shorthand for all predictors

model_fn(speed_fpm ~ ., data = elevators_train)

Inline functions / transformations

model_fn(log10(speed_fpm) ~ ns(capacity_lbs, df = 3) + ., data = elevators_train)

Downsides to formulas

You can’t nest in-line functions such as model_fn(y ~ pca(scale(x1), scale(x2), scale(x3)), data = dat).
All the model matrix calculations happen at once and can’t be recycled when used in a model function.
For very wide data sets, the formula method can be extremely inefficient.
There are limited roles that variables can take which has led to several re-implementations of formulas.
Specifying multivariate outcomes is clunky and inelegant.
Not all modeling functions have a formula method (consistency!).

Specifying models without formulas

Some modeling function have a non-formula (XY) interface. This usually has arguments for the predictors and the outcome(s):

# Usually, the variables must all be numeric
pre_vars <- c("capacity_lbs", "elevators_per_building")
model_fn(x = elevators_train[, pre_vars],
         y = elevators_train$speed_fpm)

This is inconvenient if you have transformations, factor variables, interactions, or any other operations to apply to the data prior to modeling.

Overall, it is difficult to predict if a package has one or both of these interfaces. For example, lm only has formulas.

There is a third interface, using recipes that will be discussed later that solves some of these issues.

A linear regression model

Let’s start by fitting an ordinary linear regression model to the training set. You can choose the model terms for your model, but I will use a very simple model:

simple_lm <- lm(speed_fpm ~ borough + capacity_lbs, data = elevators_train)

Before looking at coefficients, we should do some model checking to see if there is anything obviously wrong with the model.

To get the statistics on the individual data points, we will use the awesome broom package:

simple_lm_values <- augment(simple_lm)
names(simple_lm_values)
#>  [1] ".rownames"    "speed_fpm"    "borough"      "capacity_lbs" ".fitted"
#>  [6] ".resid"       ".hat"         ".sigma"       ".cooksd"      ".std.resid"

Fitting via tidymodels

The parsnip package

A tidy unified interface to models
lm() isn’t the only way to perform linear regression
- glmnet for regularized regression
- stan for Bayesian regression
- keras for regression using tensorflow
But…remember the consistency slide?
- Each interface has its own minutiae to remember
- parsnip standardizes all that!

Parsnip in action

Create specification
Set the engine
Fit the model

spec_lin_reg <- linear_reg()
spec_lin_reg
#> Linear Regression Model Specification (regression)
#>
#> Computational engine: lm

spec_lm <- spec_lin_reg %>% set_engine("lm")
spec_lm
#> Linear Regression Model Specification (regression)
#>
#> Computational engine: lm

fit_lm <- fit(
  spec_lm,
  speed_fpm ~ borough + capacity_lbs,
  data = elevators_train
)

fit_lm
#> parsnip model object
#>
#>
#> Call:
#> stats::lm(formula = speed_fpm ~ borough + capacity_lbs, data = data)
#>
#> Coefficients:
#>          (Intercept)       boroughBrooklyn      boroughManhattan
#>            4.930e+00            -2.186e-02             5.677e-01
#>        boroughQueens  boroughStaten Island          capacity_lbs
#>           -4.723e-02            -2.412e-01            -7.881e-07

Note: Models have default engines. We don’t really need to use set_engine("lm") for this example.

Alternative engines

With parsnip, it is easy to switch to a different engine, like Stan, to run the same model with alternative backends.

spec_stan <-
  spec_lin_reg %>%
  # Engine specific arguments are
  # passed through here
  set_engine("stan", chains = 4, iter = 1000)

# Otherwise, looks exactly the same!
fit_stan <- fit(
  spec_stan,
  speed_fpm ~ borough + capacity_lbs,
  data = elevators_train
)

coef(fit_stan$fit)
#>          (Intercept)      boroughBrooklyn     boroughManhattan
#>         4.929452e+00        -2.204789e-02         5.681654e-01
#>        boroughQueens boroughStaten Island         capacity_lbs
#>        -4.635465e-02        -2.409999e-01        -7.730200e-07

coef(fit_lm$fit)
#>          (Intercept)      boroughBrooklyn     boroughManhattan
#>         4.929949e+00        -2.185820e-02         5.677203e-01
#>        boroughQueens boroughStaten Island         capacity_lbs
#>        -4.723221e-02        -2.411620e-01        -7.880605e-07

Duplicate computations

Note that, for both of these fits, some of the computations are repeated.

For example, the formula method does a fair amount of work to figure out how to turn the data frame into a matrix of predictors.

When there are special effects (e.g. splines), dummy variables, interactions, or other components, the formula/terms objects have to keep track of everything.

In cases where there are a lot of predictors, these computations can consume a lot of resources. If we can save them, that would be helpful.

The answer is a workflow object. These bundle together a preprocessor (such as a formula) along with a model.

A modeling workflow

We can optionally bundle the recipe and model together into a ~~pipeline~~ workflow:

reg_wflow <-
  workflow() %>%    # attached with the tidymodels package
  add_model(spec_lm) %>%
  add_formula(speed_fpm ~ borough + capacity_lbs) # or add_recipe() or add_variables()

reg_fit <- fit(reg_wflow, data = elevators_train)
reg_fit
#> ══ Workflow [trained] ══════════════════════════════════════════════════════════
#> Preprocessor: Formula
#> Model: linear_reg()
#>
#> ── Preprocessor ────────────────────────────────────────────────────────────────
#> speed_fpm ~ borough + capacity_lbs
#>
#> ── Model ───────────────────────────────────────────────────────────────────────
#>
#> Call:
#> stats::lm(formula = ..y ~ ., data = data)
#>
#> Coefficients:
#>            (Intercept)         boroughBrooklyn        boroughManhattan
#>              4.930e+00              -2.186e-02               5.677e-01
#>          boroughQueens  `boroughStaten Island`            capacity_lbs
#>             -4.723e-02              -2.412e-01              -7.881e-07

Swapping models

stan_wflow <-
  reg_wflow %>%
  update_model(spec_stan)

set.seed(21)
stan_fit <- fit(stan_wflow, data = elevators_train)
stan_fit
#> ══ Workflow [trained] ══════════════════════════════════════════════════════════
#> Preprocessor: Formula
#> Model: linear_reg()
#>
#> ── Preprocessor ────────────────────────────────────────────────────────────────
#> speed_fpm ~ borough + capacity_lbs
#>
#> ── Model ───────────────────────────────────────────────────────────────────────
#> stan_glm
#>  family:       gaussian [identity]
#>  formula:      ..y ~ .
#>  observations: 26112
#>  predictors:   6
#> ------
#>                        Median MAD_SD
#> (Intercept)             4.9    0.0
#> boroughBrooklyn         0.0    0.0
#> boroughManhattan        0.6    0.0
#> boroughQueens           0.0    0.0
#> `boroughStaten Island` -0.2    0.0
#> capacity_lbs            0.0    0.0
#>
#> Auxiliary parameter(s):
#>       Median MAD_SD
#> sigma 0.7    0.0
#>
#> ------
#> * For help interpreting the printed output see ?print.stanreg
#> * For info on the priors used see ?prior_summary.stanreg

Workflows

Once the first model is fit, the preprocessor (i.e. the formula) is processed and the model matrix is formed.

New models don’t need to repeat those computations.

Some other nice features:

Workflows are smarter with data than model.matrix() in terms of new factor levels.
Other preprocessors can be used: recipes and dplyr::select() statements (that do no data processing).
As will be seen later, they can help organize your work when a sequence of models are used.
A workflow captures the entire modeling process (mentioned earlier) and a simple fit() and predict() sequence are used for all of the estimation parts.

Using workflows to predict

# generate some bogus data (instead of using the training or test sets)
set.seed(3)
shuffled_data <- map_dfc(elevators, ~ sample(.x, size = 10))

predict(stan_fit, shuffled_data) %>% slice(1:3)
#> # A tibble: 3 × 1
#>   .pred
#>   <dbl>
#> 1  4.93
#> 2  4.93
#> 3  4.88
predict(stan_fit, shuffled_data, type = "pred_int") %>% slice(1:3)
#> # A tibble: 3 × 2
#>   .pred_lower .pred_upper
#>         <dbl>       <dbl>
#> 1        3.48        6.45
#> 2        3.52        6.31
#> 3        3.40        6.30

The tidymodels prediction guarantee!

The predictions will always be inside a tibble.
The column names and types are unsurprising.
The number of rows in new_data and the output are the same.

This enables the use of bind_cols() to combine the original data and the predictions.

Evaluating models

tidymodels has a lot of performance metrics for different types of models (e.g. binary classification, etc).

Each takes a tibble as an input along with the observed and predicted column names:

pred_results <-
  augment(stan_fit, shuffled_data)

# Data was randomized; these results should be bad
pred_results %>% rmse(truth = speed_fpm, estimate = .pred)
#> # A tibble: 1 × 3
#>   .metric .estimator .estimate
#>   <chr>   <chr>          <dbl>
#> 1 rmse    standard        345.

Multiple metrics/KPIs

A metric set can bundle multiple statistics:

reg_metrics <- metric_set(rmse, rsq, mae, ccc)

# A tidy format of the results
pred_results %>% reg_metrics(truth = speed_fpm, estimate = .pred)
#> # A tibble: 4 × 3
#>   .metric .estimator  .estimate
#>   <chr>   <chr>           <dbl>
#> 1 rmse    standard   345.
#> 2 rsq     standard     0.0844
#> 3 mae     standard   290.
#> 4 ccc     standard    -0.000280

broom methods

parsnip and workflow fits have corresponding broom tidiers:

glance(reg_fit)
#> # A tibble: 1 × 12
#>   r.squared adj.r.squared sigma statistic p.value    df  logLik    AIC    BIC
#>       <dbl>         <dbl> <dbl>     <dbl>   <dbl> <dbl>   <dbl>  <dbl>  <dbl>
#> 1     0.143         0.143 0.729      873.       0     5 -28803. 57621. 57678.
#> # … with 3 more variables: deviance <dbl>, df.residual <int>, nobs <int>
tidy(reg_fit)
#> # A tibble: 6 × 5
#>   term                       estimate  std.error statistic      p.value
#>   <chr>                         <dbl>      <dbl>     <dbl>        <dbl>
#> 1 (Intercept)             4.93        0.0126       392.    0
#> 2 boroughBrooklyn        -0.0219      0.0151        -1.45  0.147
#> 3 boroughManhattan        0.568       0.0136        41.9   0
#> 4 boroughQueens          -0.0472      0.0170        -2.77  0.00559
#> 5 `boroughStaten Island` -0.241       0.0425        -5.68  0.0000000135
#> 6 capacity_lbs           -0.000000788 0.00000172    -0.457 0.647

Hands-On: Fit a model

Go to the lab and try to fit some models. The labs include the skeleton. Try to mix it up with different predictors or models.
